About This Product:
- Max AC Output VA: 1200
- Rated AC Output VA: 1000
- Starting System: Recoil Start
- Fuel Consumption: 0.60 liters/hr (approx.)
- Run Time: 12.5 hours
Special Highlight:
This is India’s lightest and most fuel-efficient 1.2 KVA genset. It can also run on LPG cylinders and generate electricity at an economical price.
Application:
Ideal for home and shop use, this genset is perfect for areas with long power cuts (over 12 hours). It can charge inverter batteries and power household appliances such as water pumps, refrigerators, TVs, coolers, and more. Its lightweight design makes it perfect for fieldwork, mobile applications, and picnic camps.
This premium product is the result of exceptional effort from HPM's R&D engineers. Himalayan Power, with over 25 years of experience, offers complete power and lighting solutions through over 300 products and models. As a 100% "Make in India" company, HPM provides after-sales services and spare parts at very affordable prices.
Panel & Other Standard Features
- Voltmeter : Yes (Analogue)
- Digital Hour Meter : No
- Oil Alert System : Yes
- LPG/ Gas Fuel Compatibility : Yes (Optional)
- AMF Panel Auto & Remote Start Compatibility : No
- Fuel Level Gauge : Yes
- Overload Protection (NFB) : Yes
- Costar Wheels : Optional
Specifications
| Category |
Specifications |
| Alternator |
| Alternator Max. Current Capacity |
12 Amps |
| Alternator |
Brushless, Rare Earth Magnetic Rotor, THD = 5 %, Pure Sine Wave |
| Engine |
| Engine Model |
HM156P |
| Type |
OHV25°Inclined, Single Cylinder, 4 Strokes, S.I, Forced Air Cooling |
| Maximum Power |
3.0 hp @ 3600rpm |
| Bore x Stroke |
56mm × 40mm |
| Displacement |
98cc |
| Starting System |
Recoil Start |
| Fuel |
Petrol + LPG (Optional) |
| Fuel Tank Capacity |
7.5 Ltr |
| Fuel Consumption |
0.60 Ltr/hr Approx. (At Rated Load) |
| Continuous Running (With One Filling) |
12.5 Hrs |
| Lube Oil Capacity |
400 ml |
| Lubricating Oil Consumption |
6.5 gm/kW·h |
| Sound Level (from 1 meter) |
<86dB |
| Size & Weight |
| Approx. Weight |
32.5 KG |
| Dimensions (LxWxH) |
500mm × 365mm × 460mm |
